introduction.

Introducing the Broadband

Networking 5-Port Switch

Congratulations on your purchase of the Microsoft

Broadband

Networking 5-Port Switch. The switch can be used in a number of

different ways. It will let you expand your existing Ethernet network

by connecting additional computers, printers, scanners, and other

Ethernet devices. The switch will also let you form a new local area

network (LAN) by connecting two or more computers. A typical

network configuration that includes a switch is illustrated in the

following example:

Note

Each computer that connects

to your switch requires an

Ethernet adapter or available

Ethernet port.

Active Internet Connection

Broadband Modem

(DSL or Cable)

5-Port Switch

Base Station

(Gateway or Router)

Computers with

Installed Ethernet

Adapters
